main parameter:
| Model | WXR-320 | WXR-420 |
| Maximum feed width | 350mm | 420mm |
| Max.rewinding diameter | 500mm | 500mm |
| Max.winding diametcr | 480mm | 500mm |
| Cutting and precision | 士0.10mm | 士0.10mm |
| Cutting speed | 120/140/180m/min | 120m/min |
| Narrowest slitting | 8mm | 8mm |
| Positioningaccuracy | 330mm | 410mm |
| The motor power | 220v | 220v |
| The power supply | 1500W/3KW | 1500W/3KW |
| Machine dimension | 1100*800*1280mm | 1200*900*1200mm |
| Machine weight | About 400kg | About 500kg |
main features:
◎Compared with the round cutter die-cutting machine faster, more efficient, simple operation, smooth operation;
◎With automatic meter counting, automatic stop, photoelectric eye deviation correction and other functions;
◎ It is a four-axis coil changing and cutting machine with cutting function. With high precision round cutter die-cutting system;
◎ Used for blank sticker, die - cutting, cutting can be completed at one time.
Scope of application:◎Suitable for cutting protective film, PET, insulating material, mylar, industrial tape, adhesive products and various electronic material
